Beskrivelse
Material | Stainless Steel |
---|---|
Finish | Electropolished |
Access Restriction | No Restriction |
Grip Type | Adjustable |
Mounting Style | Single Hole Mount |
Head Style | Knob Style |
Series | Standard |
Min. Outer Panel Thickness (mm) | 0.00 |
Max Outer Panel Thickness (mm) | 13.00 |
Grip – Minimum (mm) | 6.40 |
Grip – Maximum (mm) | 9.50 |
Cam Attached | Yes |
Rotation | Type A – Turn Clockwise to Latch |
Actuator Type | Cylinder Lock |
Compliance Specification | UL FTTA2 / FTTA8 Type 1 |
Latching Points | Single or Three – Point |
Class | E3 – VISE ACTION® Compression Latches |
Size | 13.5mm |
